Dry Type Transformers

No Oil. Enhance Safety.

Cast resin dry-type transformers up to 2500 kVA, 33 kV.

Technical Specifications

Parameter Specification
Capacity range 100 kVA to 2500 kVA
Voltage class Up to 33 kV
Insulation class Class F or Class H
Cooling AN / AF
Enclosure protection IP Protection for Indoor and Outdoor applications
Standards IEC, IS, ANSI, IEEE
Winding material Electrolytic Grade Copper or Aluminium
Winding type HV: Foil / Crossover / Spiral / Disc  |  LV: Foil / Spiral / Disc / Helical
Tapping range Off-Circuit Tap with Links / OLTC
Frequency 50 Hz / 60 Hz
Temperature rise As per IS / IEC requirements
Testing Complete Routine Tests as per IEC, IS, ANSI, IEEE. Type Tests available on request.

Optional Features

  • RTD temperature monitoring for windings and core
  • Digital Temperature Indicator
  • Automatic fan control system
  • Remote monitoring and SCADA compatibility
  • Anti-condensation space heaters
  • Seismic-resistant design
  • Special enclosures up to IP55

Specify Your Dry-Type Transformer.

Share your kVA rating, voltage class, installation environment (indoor/outdoor / basement / plantroom), and enclosure requirement we will recommend the right insulation type and cooling class for your application.
